C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
80
Tilting the mast while the engine is stopped (emergency movement)
It is possible to tilt the mast of the forklift (emergency movement) forwards with the
ignition off. To do so, proceed as follows:
- Locate the emergency movement connector under the dash panel, next to the
steering column (fig. 1)
- Remove the protective cover from the connector by lifting the locking tab and
moving it forwards.
- With the help of an external battery supply the connector with + 12V DC and
earth (-) as follows:
Connector, contact 1: + 12V DC
Connector, contact 2: earth (-)
- Push the joystick to the right in order to tilt the mast.
NOTE
To help this movement, we recommend applying a small load on the end of
the forks.
(fig. 1)
Special procedures
