Austroflamm Flok 2.0 - Technical Data

Flok 2.0 english
12
1. TECHNICAL DATA
As a stove of construction type 1, it is possible to connect
it to the chimney together with an existing other stove or
another hearth for solid fuels, as long as the chimney
dimensioning calculation complies with DIN 4705, Part 3.
TECHNICAL DATA
Height
958 mm
Width
425 mm
Depth
417 mm
Weight
110 kg
Flue pipe outlet diameter
130 mm
Nominal thermal output (EN 13240)
4 kW
Maximum thermal capacity
6 kW
Smallest heating capacity
2,5 kW
Room heating capacity (depending on
building insulation)
34 - 88m³
Technical data according to Regulation (EU) 2015/1185 and delegated Regulation (EU)
2015/1186
Contact details for the manufacturer or their authorised representative
Manufacturer:
Austroflamm GmbH
Contact:
-
Address:
Austroflamm-Platz 1
4631 Krenglbach
Austria
Appliance details
Model identification(s):
Flock 2.0
Equivalent models:
-
Test reports:
RRF – 40 12 3120
Applied harmonized standards:
EN 13240
Other standards/technical specifications. Specifications:
Indirect heating function:
No
Direct heat output:
4.0
Indirect heat output
1
:
-
Properties for operation with the preferred fuel
Space heating annual use efficiency η
s
:
70.9
Energy efficiency index (EEI):
107
Exhaust values for multiple use of the chimney in
accordance with DIN 4705, Part 3 and for the calculation of
the chimney measurements in accordance with DIN 4705,
Part 2
Fluegas mass flow
closed
3,92 g/s
Fluegas temperature
closed
343 °C
Minimum feed pressure
Nominal thermal output
closed
12 Pa
at 0.8 times n.
ther. outp.
10 Pa
Subject to technical and optical modifications. Formatting and printing errors excepted.
