26
8) Press Y button or gently actuate and then release the brake pedal
as instructed to continue.
9) Use UP/DOWN button to view onscreen prompts
prompt screen to be continued…
10) Press Y button to continue.
l The black block “ ” in the screen indicates specified
pressure range of current phase.
11) Operate the brake pedal gently to raise the pressure to 4.5-5.5 bar
and hold it for 5 seconds as instructed.
........ Inspect Brake Air .... .
2.3 bar
0 25
↑
Hold pressure within
black range for 5s.
........ Inspect Brake Air .... .
1/2
1. Increase brake
pressure slowly and
evenly.
2. Brake pressure must
not rise beyond the
specified range!
........ Inspect Brake Air .... .
2/2
3. Actual value should
be within the black
range and be held
for 5s.
4. [Y] =Con. [N] =Return
To Next Page
