27
l If the pressure can not reach the specified range for a long
period, hold N button for about 2s to exit, and a “User
Aborted!” message shows on the display.
l Whenever you operate the pedal too hard and the pressure is
raised beyond the specified range of current phase,
following screens come up prompting you to repeat the
process to try again:
prompt screen to be continued…
12) Continue to operate the pedal gently to increase the pressure to
9.5-10.5 bar and keep it for 5s.
........ Inspect Brake Air .... .
4.5 bar
0 25
↑
Hold pressure within
black range for 5s.
........ Inspect Brake Air.... .
1/2
1. Brake pressure must
not rise beyond the
specified range!
2. Repeat the process.
3. Press [Y] or
gently actuate and
........ Inspect Brake Air.... .
2/2
then release the
brake pedal to
continue.
4. [N]= Return.
