28
13) Keep operate the pedal to increase the pressure to 19.5-20.5 bar
and hold it for 5s.
14) Follow onscreen instructions to finish current phase of operation:
- Release brake pedal.
- A strong brake pedal kickback indicates a fault.
- Did brake pedal pulse weakly?
- If YES, press [Y] or gently actuate and then release the brake
pedal to continue.
- If NO, press [N].
15) Press Y button or gently actuate and then release the pedal to
continue, and the device starts to communicate with the vehicle.
16) Use UP/DOWN button to view onscreen prompts
prompt screen to be continued…
17) Press Y button and following screen shows:
........ Inspect Brake Air .... .
0.1 bar
0 25
↑
Hold pressure within
black range for 5s.
........ Inspect Brake Air .... .
1/2
1. Increase brake
pressure slowly and
evenly.
2. Actual value should
be within the black
range and be held
........ Inspect Brake Air .... .
2/2
for 5s.
3. [Y] =Con. [N] =Return
