SPECIFICATIONS
PART NUMBERS
60kW: UF060xxxxx; 80kW: UF080xxxxx; 140kW: UF140xxxxx; 160kW: UF160xxxxx;
100kW: UF100xxxxx; 120kW: UF120xxxxx 180kW: UF180xxxxx; 200kW: UF200xxxxx;
220kW: UF220xxxxx; 240kW: UF240xxxxx
The "xxxxx" portion of the product part number represents the various product congurations.
ELECTRICAL
CONNECTOR OPTION* Dual CCS1, or CCS1 + CHAdeMO Dual CCS1/CCS1 Boost, or CCS1 +CHAdeMO
MAX. INPUT AC CURRENT
60kW: 91A; 80kW: 122A; 140kW: 213A; 160kW: 245A; 180kW: 270A;
100kW: 152A; 120kW: 182A 200kW: 305A; 220kW: 335A; 240kW: 365A
NOMINAL INPUT AC CURRENT 60kW: 83A; 80kW: 110A; 140kW: 181A; 160kW: 207A; 180kW: 230A;
100kW: 138A; 120kW: 165A 200kW: 260A; 220kW: 285A; 240kW: 310A
INPUT VOLTAGE RANGE 480 V AC - 15 % to +10 % @ 60 Hz
DC OUTPUT VOLTAGE CCS1: 150 to 950 V DC; CHAdeMO: 150 to 500 V DC
TN-S, TN-C, TN-C-S, & TT (External RCD** Required)
AC INPUT CONNECTION 3P + PE (No Neutral)
PROTECTION Over-Current, Over-Voltage, Under-Voltage, Ground-Fault, Over-Temperature,
Short-Circuit, Insulation Monitor (IMD), & Surge Protection
AC Side (Input) OVC: III
POWER FACTOR (> % LOAD) ≥ 0.98
THDI (> % LOAD) ≤ 5 %
≥ 96 %
80 W
SHORT CIRCUIT CURRENT RATING ≥ 65 kA
Class A
USER INTERFACE & COMMUNICATION
Internet Access Via 4G / Wi-Fi / Ethernet (RJ 45)
USER AUTHENTICATION QR Code, RFID, Credit Card (Optional)
ISO PLUG & CHARGE Yes
DIN Yes
INTERFACE 27” LCD High-Contrast Touchscreen (15.6” Optional)
ACCESSIBLE FOR WHEELCHAIR USERS Yes
COMMUNICATIONS PROTOCOLS OCPP 1.6 JSON, OCPP 2.0.1 (Can Be Upgraded Later)
RFID READER ISO 14443 A+B to Part 4 & ISO/IEC 15693, Mifare, NFC, Calypso, Ultralight, PayPass, HID & More
Yes
SOFTWARE UPDATE OTA Update Via Web Portal
CONTROL AND CONFIGURATION Web Portal, On-Board Service Portal
GENERAL CHARACTERISTICS
PROTECTION RATINGS NEMA 3R Outdoor Use & IK-10
Stainless Steel 430
OPERATION ALTITUDE 6561 Ft. (6561 to 9843 Ft. with Power Derating)
OPERATING TEMPERATURE -31 °F to +131 °F (+122 °F to +131 °F with Linear Power Derating)
STORAGE TEMPERATURE -40 °F to +158 °F
< 95 % RH, Non-Condensing
NOISE LEVEL < 65 dB @1 m/25 °/Full Load/800 VDC
MOUNTING Free-Standing Cabinet
CABLE LENGTH 15 ft (Optional: 20 or 25 ft)
DIMENSIONS (H X W X D) 76.8 x 32.3 x 23.6 In. (1950 x 820 x 600 mm) 76.8 x 32.3 x 27.6 In. (1950 x 820 x 700 mm)
CERTIFICATIONS & STANDARDS
UL 2202, UL 2231-1, UL 2231-2, NEC Article 625, CSA C22.2 No. 107.1-16
EMC COMPLIANCE FCC Part 15 Class A, Class B (Optional)
24 Months with Warranty Extensions Available
* CCS1 Max 200A, CCS1 Boost 300A (Max 400A) ** RCD: Residual Current Detector For Ground Fault Protection
MAXICHARGER DC FAST 60KW-240KW WITH 20KW INCREMENTS
1.844.765.0150 I WWW.AUTELENERGY.COM I AUTELENERGY@AUTEL.COM
DCFC 60KW-120KW DCFC 140KW-240KW
