24
3.5 MODES SET UP
The AA702 base station must be powered up and the AA710 remote console
must be turned off to access the Set up Menu.
The AA710 system can be set up to operate your choice of equipment on the boat. The
standard kit has one master base station and one console. Each base station has 6 outputs.
Up to 2 slave stations can be attached to the master station to provide extra outputs. The
default system is 1 windlass located on the bow. The options available are explained below,
followed by examples of system setups. See also the table of output options on page 26.
3.5.1 WINDLASS SETTINGS
Allocate the outputs for windlasses and anchoring operations in the Modes menu.
3.5.1.1 Windlass Location - Outputs 1 and 2 (Default is 1 windlass)
If you have more than one windlass you will need to allocate the outputs and enter the
windlass locations into the system. An individual base station is required for each windlass
. The windlass outputs must be Output 1 and Output 2. The outputs are operated using the
up and down buttons.
3.5.1.2 Windlass Options - Outputs 3 and 4
Option A and B can be used from the Windlass page for functions associated with
anchoring. For example: decklights, deck wash, anchor stow, power cleat.
Option A is operated using the left arrow button and controls Output 3.
Option B is operated using the right arrow button and controls Output 4.
Both options can be set as momentary or toggle switches.
3.5.1.3 Autowash - Output 5
Turns on the anchor wash pump automatically when the anchor is retrieved.
3.5.1.4 Dual Speed - Output 6
Use to operate a windlass with a dual speed motor. Dual speed is controlled by the right
arrow button and sends a Fast/Slow signal to Output 6.
3.5.2 THRUSTER SETTINGS - Outputs 3, 4, 5 and 6
The default locations can be swapped in the Setup menu. The port and starboard
directions for each output cannot be changed.
Allocate the outputs and set the thruster location in the Modes menu. The thrusters are
operated from the thruster page using the left and right arrow buttons.
Thruster A
Default Location Bow
Output 3 - Port
Output 4 - Starboard
Thruster B
Default Location Stern
Output 5 Port
Output 6 - Starboard
