Page 12 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
Wall Mounted Enclosure Installation Reference
Figure 3: Enclosure Install Reference
Note: A system ground must be provided for Earth Detection and transient protection devices. This connection shall be made to an approved, dedi-
cated Earth connection per NFPA 70, Article 250, and NFPA 780.
Additional 4100ES Technical Reference
Table 18: Additional technical documents
Document Document Number
Installation Instructions 574-848AC
Operating Instructions 579-197AC
