Page 13 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
General Specifications
Table 19: NDU General Specifications
Specification Rating
120 VAC Models 4 A maximum @ 102 to 132 VAC, 60 Hz
Input Power [System (SPS); Expansion (XPS); Remote
(RPS); and 100 W amplifiers]
220-240 VAC Models
2 A maximum @ 204 to 264 VAC, 50/60 Hz; separate taps for
220/230/240 VAC
Total Power Supply
Output Rating
Including module currents and auxiliary power outputs; 9 A total for
"Special Application" appliances; 4 A total for "Regulated 24 DC" power
Auxiliary Power Tap 2 A maximum @ nominal 28 VDC
Power Supply Output
Ratings for SPS, XPS,
and RPS (see data sheet
AC4100-0031 for more
detail)
NACs Programmed for
Auxiliary Power
2 A maximum per NAC; 5 A
maximum total
Rated 19.1 to 31.1 VDC
Output
switches to
battery during
AC failure or
brownout
Battery capacity range
UL listed for battery charging of 6.2 Ah up to 110 Ah (batteries larger than 50 Ah require a
remote battery cabinet); ULC listed for charging up to 50 Ah batteries
Battery Charger Ratings
for SPS and RPS (sealed
lead-acid batteries)
Charger characteristics
and performance
Temperature compensated, dual rate, recharges depleted batteries within 48 hours per UL
Standard 864, to 70% capacity in 12 hours per ULC Standard S527
Operating Temperature Range 32° to 120°F (0° to 49° C)
Environmental
Operating Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Additional 4100ES and 4120 Network Product Reference
Subject Data Sheet
Serial DACT (SDACT) for 4100ES, 4010ES, 4007ES AC2080-0009
Battery and Battery Cabinet Reference for 4100ES AC2081-0006
110 Ah Batteries and Cabinets for 4100ES AC2081-0012
External 110 Ah Battery Charger for 4100ES, 4010ES AC4081-0002
TCP/IP Physical Bridge Modules for 4120 Networks AC4100-0029
4100ES Basic Panels with SPS Power Supplies AC4100-0031
4100ES LED/Switch Modules & Printer AC4100-0032
4100ES Emergency Voice/Alarm Equipment AC4100-0034
4100ES Enclosures AC4100-0037
InfoAlarm Command Center with SPS Power Supplies AC4100-0045
Multiple Signal Fiber Optic Modems for 4120 Networks AC4100-0049
BACpac Ethernet Module AC4100-0051
4120 Network Products and Specifications AC4100-0056
Physical Bridge Modules for 4120 Networks AC4100-0057
Building Network Interface Card (BNIC) AC4100-0061
SafeLINC Internet Interface AC4100-0062
4100ES Basic Panels with EPS Power Supplies AC4100-0100
InfoAlarm Command Center with EPS Power Supplies AC4100-0101
NDU with EPS Power Supplies for 4120 Network AC4100-0102
TrueSite Workstation AC4190-0016
Network System Integrator (NSI) for 4120 Networks AC4190-0017
TrueSite Incident Commander AC4190-0020
