VCC, Emergency Voice/Alarm Communications Selection
SKU Description Details and Mounting Reference
A100-1243
Master Microphone Module; one maximum per
audio system; mounts on front panel
Requires 2 Slots (4" [102 mm]), locate on expansion bay only; space behind for
4100ES flat modules only Supv. current = 2.4 mA; Active current = 6 mA
A100-1252 1 Channel (audio or mike)
A100-1253 1.5 Channel (audio + mike)
A100-1254 2 Channel (full audio)
A100-1255 3-8 Channel
Operator
Interface
Modules
Single slot modules requiring connection to an LED/switch controller; space behind
controller accepts 4100ES flat modules only
Additional adjacent LED/switch module(s) are required for specific speaker circuit
selection
Table 6: Firefighter Telephone System Products
SKU Description Details and Mounting Reference
A100-1270
Master Telephone with Telephone Control Module
and 3 Class B telephone NACs; for Fire Alarm
Control Panels
One max. per audio system; front panel module; space behind for 4100ES flat
modules only; telephone control module mounts on bay module mounting plate;
use LED/switch modules for circuit control
A100-1272 Telephone Module with 3 phone NACs Class B NACs, single Block module, mounts to bay mounting plate
A100-1273 Telephone Class A Adapter Module Mounts to A100-1272, no additional space required
Note: Refer to AC4100-0034 for additional detail.
Table 7: Analog Emergency Voice/Alarm Communications Equipment, Constant Supervision Compatible
SKU Description Details
A100-9620
Basic Analog Audio Operation with microphone, requires
dedicated expansion bay
Includes: Expansion Bay, A100-1210 Analog Controller Board,
Microphone Module, and Audio Expansion Bay Kit
A100-1210
Analog Controller Board only; order expansion bay and audio
expansion bay kit separately
Controller board mounts in Blocks A and B
A100-1361 25 VRMS output NAC rating = 1.4 A
A100-1362 70.07 VRMS output
Flex-35, 35 W Amplifier, constant
supervision compatible
NAC rating = 0.5 A
35 W, or 100
speakers
A100-1312 25 VRMS output NAC rating = 2 A
A100-1313 70.7 VRMS output
Flex-50, 50 W Amplifier, constant
supervision compatible
Includes three on-board
Class B audio NACs; power is
supplied from an XPS, RPS,
or SPS
NAC rating = 0.707 A
50 W, or 100
speakers
Table 8: 100 W Analog Amplifiers with Power Supply, Constant Supervision Compatible*
SKU/Output Voltage
25 VRMS 70.7 VRMS
Power Supply Input/Listing Description Details
A100-1314 A100-1315 120 VAC, 60 Hz UL
A100-1318 A100-1319 220/230/240 VAC, 50/60 Hz UL
Primary 100 W
Amplifier
Includes six, Class B audio NACs; NAC rating = 50
W or 100 speakers maximum; 2 A @ 25 VRMS; 1.4
A @ 70.7 VRMS
A100-1320 A100-1321 120 VAC, 60 Hz UL
A100-1324 A100-1325 220/230/240 VAC, 50/60 Hz UL
Backup 100 W
Amplifier
Uses the six Class B NACs of primary amplifier
ULC models
have low
battery
dropout
circuit
Table 9: Digital Emergency Voice/Alarm Communications Equipment*
SKU Description Details
A100-9621
Basic Digital Audio Operation with microphone, requires
dedicated expansion bay
Includes: Expansion Bay, A100-1311 Digital Controller Board,
Microphone Module, and Audio Expansion Bay Kit
A100-1311
Eight Channel Digital Controller Board only; order expansion
bay and audio expansion bay kit separately
Controller board mounts in Blocks A and B
A100-1363 25 VRMS output NAC rating = 1.4 A
A100-1364 70.07 VRMS output
Flex-35, 35 W Amplifier, constant
supervision compatible
NAC rating = 0.5 A
35 W, or 100
speakers
A100-1326 25 VRMS output NAC rating = 2 A
A100-1327 70.7 VRMS output
Flex-50, 50 W Amplifier, constant
supervision compatible
Includes three on-board
Class B audio NACs; power is
supplied from an XPS, RPS,
or SPS
NAC rating = 0.707 A
50 W, or 100
speakers
Note: * Refer to document AC4100-0034 for additional audio module information.
Table 10: 100 W Digital Amplifiers with Power Supply, Constant Supervision Compatible*
SKU/Output Voltage
25 VRMS 70.7 VRMS
Power Supply Input/Listing Description Details
A100-1328 A100-1329 120 VAC, 60 Hz UL
A100-1332 A100-1333 220/230/240 VAC, 50/60 Hz UL
Primary 100 W
Amplifier
Includes six, Class B audio NACs; NAC rating = 50
W or 100 speakers maximum; 2 A @ 25 VRMS; 1.4
A @ 70.7 VRMS
A100-1334 A100-1335 120 VAC, 60 Hz UL
A100-1338 A100-1339 220/230/240 VAC, 50/60 Hz UL
Backup 100 W
Amplifier
Uses the six Class B NACs of primary amplifier
ULC
models
have low
battery
dropout
circuit
Note: * Refer to document AC4100-0034 for additional audio module information.
