AUTOCAR E-ACTT™FIRST RESPONDERS GUIDE
888-218-3611
AWE 00424 Rev. 001
7
3. Remove the cables from the top battery and press the red button on the circuit breaker.
Push RED Button to Disconnect 24V Power
Figure 7
4. If access to the battery terminals is not possible, cut the three 12V cables in the location
shown in Figure 8.
Cut these 3 cables to disconnect 12V power
Figure 8
To Next Page
