5.2.3 Analog Parameters
Code
Parameter
Name
Parameter
Explanation
Value
Range
Initial
Value
Analog
4mA DA
value
Calibration for
4mA point
0-32767
6554
Analog
20mA
DA value
Calibration for
20mA point
0-39999
3276
8
Analog
output
mode
0-20 type:
0 point is 0mA
4-20 type:
0 point is 4mA
0-10-20 type:
0-20,
4-20,
0-10-20,
4-12-20
4-20
