HANDLING / MAINTENANCE
AutoGyro_FOM_MTOsport Revision 5.0 – Issue Date 01.04.2011 8-3
To gain access to the oil reservoir hinge the rear seat forward, open and remove oil
reservoir cap and remove dipstick. Turn the engine over using the propeller in the correct
sense of rotation until you clearly hear the oil gurgle in the tank.
Insert the cleaned dipstick fully for measurement. Fill up oil according to the engine
manufacturer’s specification when required. After completion make sure the dip stick is in
place and the reservoir cap is back on securely.
CAUTION
Never attempt to turn the engine against its sense of rotation as this may lead
to damage.
8.7 Checking of Engine Coolant Level
Between flights, the engine coolant level is checked by verifying the level in the overflow
bottle is within min. and max. markings. The coolant level can be easily seen when looking
at the transparent overflow bottle from behind.
For additional details concerning this pre-flight check and a description of the more
comprehensive daily check procedure, refer to the engine manufacturer’s manual.
8.8 Tire Pressure
Main wheels ...........................................................................................1.6 Bar
Nose wheel ............................................................................................1.4 Bar
8.9 Lubrication and Greasing
Between maintenance intervals the owner/operator is entitled to do the following lubrication
and greasing:
Teeter bolt 10 h 2 grams AutoGyro S.WZ05
Pre-rotator drive
coupling sleeves
as required - AutoGyro S.WZ04
Pre-rotator belt and
pulleys
as required - AutoGyro S.WZ17
CAUTION
Any signs of wear on the teeter tower due to movement of the teeter bolt head
indicate a beginning of seizure of the teeter hinge. In most cases the
phenomenon is caused by insufficient greasing.
