Manual Conguration Mode (continued)
With this method, the Autoleads CP2 uses a
pre-determined dipswitch conguration to assign the
vehicle and steering control button functionality. The
dipswitches on the side of the interface must be
manually set to the proper vehicle conguration by
the user. These vehicle specic dipswitch settings can
be found by downloading the Autoleads ControlPro
application from www.autoleads.co.uk/controlpro
If you wish to re-assign button functions or use short
press/long press dual command functionality, please
follow the PC application or manual re-assignment
procedure.
1. Please Visit www.autoleads.co.uk/controlpro to
download the Autoleads ControlPro application
Launch the application and nd your vehicle/radio
combination.
2. Set the vehicle dipswitches according to the
application.
3. Set the radio dipswitches according to the radio
dipswitch chart below.
4. Connect the interface according to the installation
instructions.
With this method, the CP2 can be connected to a PC
in which the application assigns the vehicle and
steering wheel button functionality. To congure using
a PC, the dipswitches on the side of the interface
must all be set to the down/on position which is
the default position. When using this method, it is not
required to manually program the steering wheel
buttons when programming via App mode.
1. Visit www.autoleads.co.uk/controlpro to
download the Autoleads ControlPro PC application.
2. Connect the CP2 to the PC. When using a PC to
congure, it is not required to power the CP2
module via the 11 pin connector.
PC Application Mode
