DEFINITION OF OPTICAL SIGNALS
DL1 – Programming led (red)
It is lit in the programming phase and during the gate’s motion.
DL2 – Mains power led (green)
It is lit when the 12Vac voltage is present to the AC IN input.
DL3 – Pedestrian start led (green)
It is lit when the pedestrian start control is operated.
DL4 – Start led (green)
It is lit when the start control is operated.
DL5 – Stop led (red)
It signals the gate’s block state. The led goes off when the stop control is operated (emergency).
DL6 – Photo-cell led (yellow)
It signals the optical barrier’s state. The led goes off when the photo-cell is covered by persons or vehicles
DL7 – Photostop led (yellow)
It signals the optical barrier’s state. The led goes off when the photo-cell is covered by persons or vehicles.
DL8 - Opening limit switch led (yellow)
It signals the opening limit switch state for Motor 1. The led goes off when the opening limit switch is operated.
DL9 - Closing limit switch led (yellow)
It signals the closing limit switch state for Motor 1. The led goes off when the closing limit switch is operated.
DL10 - Opening limit switch led (yellow)
It signals the opening limit switch state for Motor 2. The led goes off when the opening limit switch is operated.
DL11 - Closing limit switch led (yellow)
It signals the closing limit switch state for Motor 2. The led goes off when the closing limit switch is operated.
DEFINITION OF TRIMMERS
RV1 – Slow-down speed
It defines the gate’s speed during the slow-down phase.
DEFINITIONS OF PROGRAMMING KEYS
P1 - Allows to insert/cancel the radio-command codes in the memory
P2 - Allows to set the motors’ work time and the M2 motor’s closing delay time
P3 - Allows to set the pause time
DEFINITIONS OF PROTECTION FUSES
F2 – Battery fuse (10A - Fast)
It disconnects the backup battery from the electronic card in case of short-circuit or electric current consumption anomalies.
F1 – Services fuse (1A - Slow)
It protects the electronic unit in case of short circuits or overcurrents on photo-cells or any other accessory devices connected to the card.
