ASA300 - K50
IMPORTANT – MANUAL
OVERIDE CAP MUST BE
ON AT ALL TIMES
GENERAL
ASA300 K50
Motor Voltage – 12 volt Motor Voltage - 12 / 24 DC
Power Absorbed – 70 watts Motor Inputs - Two
Speed – 0,019 metres per second Battery Charger – Inbuilt 12/24V
Maximum Thrust – 1500 N Receiver – Inbuilt or External
Protection Level – IP43 Limit Switches – Yes / No
Duty Cycle – 90% Pedestrian Input – Yes (NO)
Dimensions – 670L x 90W x 185H Start Input - Yes (NO)
Stroke – 30 CM Stop Input – Yes (NC)
Maximum Leaf – 3.0 metres Photocell Input – Two (NC)
Maximum Leaf Weight – 250 Kg Electric Lock – Yes 12Vdc 1A
Opening Time – 16 Seconds Slow Speed Regulator – Yes
