Automatic Systems TR490-NInstall-EN p6/16
2.5. Overall dimensions and installation plan
Fig. 3
Cable ducting
Cabling to be prepared:
Power supply: 230V single-phase + earth (3G x 2.5)
Control wiring according to specifications
50
1000
950
760
800
26.5
26.5
1000
20
60
60
265 480 265 500 265
620145 145
620
145
20
265 480 265 500 265
AAA
BBB
145
EXPANSION BOLT B15/30
-/3413/000
(recommended model)
A
B
° 15
min. 100
800
920
60
60
1220
50
840
265
190
190
Power supply and command
cable inlet area
