Getting Started with Timers
Below you will find the list of available timer modes with a brief description of operation, for more detailed infor-
mation about the timing sequences and output operations please see the associated page(s) within this chapter.
Timer Modes Description Page Number
Signal On Delay 1
On delay timer with momentary Start Input 3-4
Signal On Delay 2
On delay timer with maintained Start Input 3-6
Signal Off Delay
Off delay timer with momentary Start Input 3-8
Signal On
Off delay timer with latching Start Input 3-10
Power On Delay
On delay timer when power is applied 3-12
Power On Delay Hold
On delay timer when power is applied and actual value storage on power
loss
3-14
Repeat Cycle
Repeating On delay timer 3-16
Repeat Cycle Hold
Repeating On delay timer and actual value storage on power loss 3-18
Repeat Cycle 2
Repeating Off delay timer with separate on and off times 3-20
Signal Cumulate
On delay timer with single start and pause input and actual value storage
on power loss
3-22
Signal Twin On-Start
Off delay timer with individual setpoints for Off and On times 3-24
Signal Twin Off Start
On delay timer with individual setpoints for On and Off times 3-26
Click on the above thumbnail or go to
https://www.automationdirect.com/VID-RL-0008
for a short Timer demo video.
Click on the above thumbnail or go to
https://www.automationdirect.com/VID-RL-0007
for a Timer Set-up video.
