Chapter 4: System Design and Configuration
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
Chapter 4: System Design and Configuration
1
2
3
4
5
6
7
8
9
10
11
12
13
14
a
b
c
D
NOTE 1: Auxiliary 24VDC used to power V+ terminal of D0-06DD1/-D sinking outputs.
NOTE 2: If the PLC’s auxiliary 24VDC power source is used to power the sinking outputs, use power
choice A, above.
Power Budgeting Example
Power Source
5VDC
power (mA)
24VDC
power (mA)
D0-06DD1
(select row
A or row B)
A 1500mA 300mA
B 2000mA 200mA
Current Required
5VDC
power (mA)
24VDC
power (mA)
D0-06DD1
600mA 280mA, note 1
D0-16ND3
35mA 0
D0-10TD1
150mA 0
D0-08TR
280mA 0
F0-4AD2DA-2
100mA 0
D0-06LCD
50mA 0
Total Used
1215mA 280mA
Remaining
A 285mA 20mA
B 785mA note 2
DL06 Power Supplied by Base Units
Part Number 5 VDC (mA) 24 VDC (mA)
D0-06xx
<1500mA 300mA
<2000mA 200mA
D0-06xx-D
1500mA none
DL06 Power Consumed by Other Devices
Part Number 5 VDC (mA) 24 VDC (mA)
D0-06LCD
50mA none
D2-HPP
200mA none
DV-1000
150mA none
EA1-S3ML
210mA none
EA1-S3MLW
210mA none
DL06 Base Unit Power Required
Part Number 5 VDC (mA) 24 VDC (mA)
D0-06AA
800mA none
D0-06AR
900mA none
D0-06DA
800mA none
D0-06DD1
600mA 280mA, note 1
D0-06DD2
600mA none
D0-06DR
950mA none
D0-06DD1-D
600mA 280mA, note 1
D0-06DD2-D
600mA none
D0-06DR-D
950mA none
If the 5VDC loading is less than 2000mA, but more than
1500mA, then available 24VDC supply current is 200mA.
If the 5VDC loading is less than 1500mA, then the
available 24VDC current is 300mA.
NOTE: See the DL05/DL06 OPTIONS
manual for the module data for your project.
DL06 Power Consumed
by Option Cards
Part Number 5 VDC (mA) 24 VDC (mA)
D0-07CDR
130mA none
D0-08CDD1
100mA none
D0-08TR
280mA none
D0-10ND3
35mA none
D0-10ND3F
35mA none
D0-10TD1
150mA none
D0-10TD2
150mA none
D0-16ND3
35mA none
D0-16TD1
200mA none
D0-16TD2
200mA none
D0-DCM
250mA none
D0-DEVNETS
45mA none
F0-04TRS
250mA none
F0-08NA-1
5mA none
F0-04AD-1
50mA none
F0-04AD-2
75mA none
F0-04DAH-1
25mA 150mA
F0-04DAH-2
25mA 30mA
F0-08ADH-1
25mA 25mA
F0-08ADH-2
25mA 25mA
F0-08DAH-1
25mA 220mA
F0-08DAH-2
25mA 30mA
F0-2AD2DA-2
50mA 30mA
F0-4AD2DA-1
100mA 40mA
F0-4AD2DA-2
100mA none
F0-04RTD
70mA none
F0-04THM
30mA none
F0-CP128
150mA none
H0-CTRIO(2)
250mA none
H0-ECOM
250mA none
H0-ECOM100
300mA none
H0-PSCM
530mA none
