DL06 Micro PLC User Manual; 3rd Edition Rev. E
4–26
Chapter 4: System Design and Configuration
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
MWX Slave Memory Address
MWX Master Memory Addresses
MWX Number of Elements
MWX Exception Response Buffer
Chapter 4: System Design and Configuration
MWX Slave Address Ranges
Function Code MODBUS Data Format Slave Address Range(s)
05 – Force Single Coil 484 Mode 1–999
05 – Force Single Coil 584/984 Mode 1–65535
06 – Preset Single Register 484 Mode 4001–4999
06 – Preset Single Register 84/984 Mode
40001–49999 (5 digit) or 400001–
465535 (6 digit)
08 – Diagnostics 484 and 584/984 Mode 0–65535
15 – Force Multiple Coils 484 1–999
15 – Force Multiple Coils 585/984 Mode 1–65535
16 – Preset Multiple Registers 484 Mode 4001–4999
16 – Preset Multiple Registers 584/984 Mode
40001–49999 (5 digit) or 4000001–
465535 (6 digit)
MWX Number of Elements
Operand Data Type DL06 Range
V–memory V All
Constant K 1–2000
MWX Exception Response Buffer
Operand Data Type DL06 Range
V–memory V All
MWX Master Memory Address Ranges
Operand Data Type DL06 Range
Inputs X 0–777
Outputs Y 0–777
Control Relays C 0–1777
Stage Bits S 0–1777
Timer Bits T 0–377
Counter Bits CT 0–177
Special Relays SP 0–777
V–memory V All
Global Inputs GX 0–3777
Global Outputs GY 0–3777
