NOTE: Status flags are valid only until another instruction uses the same flag.
In the following example, when X1 is on, the LDF instruction loads C10–C13 (4 binary bits)
into the accumulator. The accumulator contents is logically ANDed with the bit pattern from
Y20–Y23 using the ANDF instruction. The OUTF instruction outputs the accumulator’s
lower four bits to C20–C23.
bbbK
ANDF A aaa
Operand Data Type DL06 Range
B
aaa bbb
Inputs X 0-777 -
Outputs Y 0-777 -
Control Relays C 0-1777 -
Stage Bits S 0-1777 -
Timer Bits T 0-377 -
Counter Bits CT 177 -
Special Relays SP 0-777 -
Constant K - 1-32
Discrete Bit Flags Description
SP63 ON if the result in the accumulator is zero.
SP70 ON if the result in the accumulator is negative
ndar dRLL
C10
K4
X1
K4
K4C10
00000000000011100000000000000000
15 14 13 12 11 10 98765 4 321031 30 29 28 27 26 25 24 23 22 21 20 19 18 17 1631 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
C10C11C12C13
Y20Y21Y22Y23
Accumulator
0000000000001000
Acc.
Acc.
0000000000000000 0000000000001110
1000
C20C21C22C23
DirectSOFT32
Load the status of 4
consecutive bits (C10-C13)
into the accumulator
ANDF
Y20
K4
And the binary bit pattern
(Y20-Y23) with the value in
the accumulator
OUTF
C20
Copy the value in the lower
4 bits in accumulator to
C20-C23
AND (Y20-Y23)
The unused accumulator bits are set to zero
Location Constant
ConstantLocation
ON
ON ON
OFF
ON OFFOFFOFF
ON
OFFOFFOFF
C20
K4
LDF
Handheld Programmer Keystrokes
1
B
ENT
1
B
4
E
0
A
0
A
ENT
STR
$
SHFT
ANDST
L
3
D
OUT
GX
SHFT
5
F
5
F
AND
V
SHFT
5
F
NEXT NEXT NEXT NEXT
NEXT
2
C
4
E
ENT
PREV PREV
0
A
2
C
4
E
ENT
DS Used
HPP Used
DirectSOFT
And Formatted (ANDF)
The ANDF instruction logically ANDs the binary value in
the accumulator with a specified range of discrete memory
bits (1–32). The instruction requires a starting location
(Aaaa) and number of bits (Kbbb) to be ANDed. Discrete
status flags indicate if the result is zero or a negative number
(the most significant bit =1).
