Automationdirect.com DL06 - Page 369

DL06 Micro PLC User Manual, 3rd Edition, Rev. E
5-208
Chapter 5: Standard RLL Instructions
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
MWX Slave Address Ranges
MWX Master Memory Address Ranges
MWX Number of Elements
MWX Exception Response Buffer
MWX Slave Address Ranges
Function Code MODBUS Data Format Slave Address Range(s)
05 – Force Single Coil 484 Mode 1–999
05 – Force Single Coil 584/984 Mode 1–65535
06 – Preset Single Register 484 Mode 4001–4999
06 – Preset Single Register 584/984 Mode
40001–49999 (5 digit) or 400001–
465535 (6 digit)
15 – Force Multiple Coils 484 Mode 1–999
15 – Force Multiple Coils 585/984 Mode 1–65535
16 – Preset Multiple Registers 484 Mode 4001–4999
16 – Preset Multiple Registers 584/984 Mode
40001–49999 (5 digit) or 4000001–
465535 (6 digit)
MWX Master Memory Address Ranges
Operand Data Type DL06 Range
Inputs X 0–1777
Outputs Y 0–1777
Control Relays C 0–3777
Stage Bits S 0–1777
Timer Bits T 0–377
Counter Bits CT 0–377
Special Relays SP 0–777
V–memory V all
Global Inputs GX 0–3777
Global Outputs GY 0–3777
Number of Elements
Operand Data Type DL06 Range
V–memory V all
Constant K Bits: 1–2000 Registers: 1–125
Number of Elements
Operand Data Type DL06 Range
V–memory V all
