CPU Specifications
Specifications
Feature DL06
Total Program memory (words)
14.8K
Ladder memory (words)
7680
Total V-memory (words)
7616
User V-memory (words)
7488
Non-volatile V Memory (words)
128
Contact execution (boolean)
<0.6us
Typical scan (1k boolean)
1-2ms
RLL Ladder style Programming
Yes
RLL and RLLPLUS Programming
Yes
Run Time Edits
Yes
Supports Overrides
Yes
Scan
Variable / fixed
Handheld programmer
Yes
DirectSOFT programming for Windows
Yes
Built-in communication ports (RS232C)
Yes
FLASH Memory
Standard on CPU
Local Discrete I/O points available
36
Local Analog input / output channels maximum
None
High-Speed I/O (quad., pulse out, interrupt, pulse catch, etc.)
Yes, 2
I/O Point Density
20 inputs, 16 outputs
Number of instructions available (see Chapter 5 for details)
229
Control relays
1024
Special relays (system defined)
512
Stages in RLL
PLUS
1024
Timers
256
Counters
128
Immediate I/O
Yes
Interrupt input (external / timed)
Yes
Subroutines
Yes
For/Next Loops
Yes
Math (Integer and floating point)
Yes
Drum Sequencer Instruction
Yes
Time of Day Clock/Calendar
Yes
Internal diagnostics
Yes
Password security
Yes
System error log
Yes
User error log
Yes
Battery backup
Optional D2-BAT-1 available
(not included with unit)
