Fiber Optic Amplier
2) One-point teach mode
※
One of teaching modes that sets the maximum sensitivity by teaching one sensitivity setting point when setting the SV
with no sensing object (Reflective) or when setting the SV with incident light level 0(Through-beam) / Suitable for the
applications required little effect of dust or background.
● Set Teaching mode parameter [
SENS
] to "
IPNT
"
Max.
3400
2760
2757
2760
2750
2500
Time
"
1P
" flashes twice (0.5sec.)
Setting value flashes twice
(0.5sec.) and automatically moved.
Setting value flashes twice
(0.5sec.) and automatically moved.
①
②
③
"
2P
" flashes twice (0.5sec.)
④
⑤
⑥
"
2PNT
" and setting v
alue flashes
twice (0.5sec.) and
automatically returned to RUN mode.
⑦
⑧
Incident
light level
Incident
light level
Incident
light level
Min.
Max.
Max.
280
250
Time
Time
Time
Min.
3400
250
3200
Min. value
teaching
Min. value
teaching
Min.
Set
Value
3400
250
2950
"
1PNT
" will be flashing
twice (0.5sec.)
"----" will be flashing
(0.5sec.) during teaching
"----" flashes (0.5sec.) during teaching
"----"
flashes
(0.5sec.) during teaching
SV will be flashing twice(0.5 sec.)
and returned to RUN mode
①
②
③
※
SV range for sensing distance.
※
Make sure that two point teaching must be done within 60 sec after one point teaching.
If not, teaching mode is cancelled and it returns to RUN mode.
Response Time Teaching when incident light level is 0 Teaching when incident light level is saturated
UFST
In case incident light level is 0, set to 10 digit. In case incident light level is saturated, set to 3980 digit.
FST
STD
LOG
In case incident light level is 0, set to 5 digit. In case incident light level is saturated,set to 9980 digit.
Set_value =
2
P
Max
+P
Min
3) Two-point teach mode
※
Suitable when incident light level is stable or when sensing object is slow or at stopped position.
※
One of teaching modes that sets the sensitivity using average value of two incident light levels obtained from two point
teaching - one point with a sensing object and the other point without a sensing object.
● Set Teaching mode parameter [
SENS
] to "
2PNT
"
Incident light level
Teaching section : Over 3 sec.
Teaching section : Over 3 sec.
Teaching section : Over 3 sec.
※
Teaching is executed while pressing
SET
key .
Press
SET
key
Press
SET
key
over 3sec.
※
Teaching is executed while pressing
SET
key .
※
Teaching is executed while pressing
SET
key .
Press
SET
key
over 3sec.
Press
SET
key
over 3sec.
Press
SET
key
