Fiber Optic Amplier
Master
unit Slave unit (RUN mode)
Master
unit
Master
unit
Slave unit
Slave unit
Master
unit
Slave unit
● Master / Slave unit display during group teach mode
Program mode flow
①
The Master unit displays channel number on the PV display part and
"
OK
" on the SV while group teaching executes.
②
Slave units display "
TCHI
" on the PV display parts and "
----
"
flashes every 0.5 sec on the each SV display parts while group
teaching executes. When teaching is completed, Slave units flash
SV twice and display "
TCHI
" on the each PV display part and
"
END
" on the SV display parts. Then, they automatically return to
RUN mode.
③
The Master unit starts teaching after transmitting teaching command
to Slave units. When teaching is completed, the Master unit flashes
SV twice and displays "
TCHI
" on the PV display part and "
END
" on
the SV display part. Then, they automatically return to RUN mode.
Program mode setting
● When entering into program mode, parameters lights ON on the PV display part and setting values flashes every 0.5 sec.
on SV display part. Use the , keys to set each setting value.
● Press the key one time after setting each parameter to save each setting and enter into next mode.
● If the key lock is set, unlock the key lock before setting parameters.
Press
SET
key
RUN mode
※
Refer to page B-16 to 17
Program mode function for further description of each
parameter.
※
Press
key for 3 sec. to return to RUN mode while in program mode.
※
Uset the
,
keys to set
1
to
5000
ms.
※
In case timer operation mode parameter [
TMOD
] is set to "
OFF
",
time setting parameter [
TIME
] is not be displayed.
Automatically moved
Display
direction
Display
direction
Display
direction
Normal
display
Normal
display
Normal
display
Percentage
display
Reversed
display
Time setting
key
Timer
operation
mode
ON
Delay
OFF
Delay
One-shot
Long distance mode Ultra Fast mode Fast mode
Press key over 3sec.
PR-1 MODE
RSPD STD
DSPF 4000
DIR 1234
TMOD OFF
TIME 2000
TMOD OFD
RSPD LONG
DSFP 999P
;E21 1P
TMOD OND TMOD SHOT
RSPD UFST RSPD FST
key
key
key
key
key key
key
key key key
