Autonomous ErgoChair - Product Overview and Components; Overall Dimensions; Parts List

OVERALL SIZE
UNIT: mm
PART LIST
650
450
1170 -1290
470-520
670 -795
670
480
735
A B
E
F
G
H
Q
Right Left
C D
I x 4 (M8 x 25mm)
J x 3 (M6 x 22mm)
K x 7 (M6 x 35mm)
P x 8 (M8)
O x 8 (Ø 8 x 17 x 1.5mm)
N x 7(Ø 6 x 14 x 1.5mm)
L x 5 (M8 x 55mm)
M x 1
