Tidy up after on-vehicle cleaning
After the on-vehicle cleaning is completed, turn off the Auto
Ignition Switches restitute the link of the Auto fuel hoses then
start the Auto to check the leakage of Auto fuel system.
At last please clean the fuel tank and hose line with test liquid
(if there is residual detergent inside fuel tank, please.). The
detailed procedure is shown as follows: drain the liquid inside
the fuel tank out and dispose it on the clean degree, and then
fill little test liquid and turn on the power. Select ?Leakage
test? item and press key [RUN] to run the unit for about 2
When the unit stops, drain the test liquid from fuel tank and
dispose the liquid as related regulation.
Tidy up and make preparation for the next cleaning.
Without return hose connecting:
Fig.07
Disconnect the fuel supply hoses (E, F) of engine fuel system
(wrap the connector when disconnecting the connector), and
then choose a proper connector and connect it to the E end.
Reconnect the fuel outlet hose of the unit well and make the
fuel return hose hanging. See Fig.07.
Stop the other end of the disconnected end (F) with a proper
stopper, (use when the fuel pump has the fuel return function
only) or remove the fuse of fuel pump or disconnect the power
cable of fuel pump.
1-C100 Cleaner & Tester; 2-Engine; 3-stopper; 4- Fuel-inlet hose
to engine; 5-Auto tank; 6-Auto filter; 7- Engine fuel supply hose;
8-Auto fuel pump;
The hose line connection of theengine without returnhose is
shown as in Fig.07.
