Autopilot REVOLVE F20 - LED Display and Control Surface; Device Outputs and Inputs; Control Knobs and Settings; Status Indicators

LED DISPLAY & CONTROL SURFACE
(
LIGHT 1 OUTPUT
) (
LIGHT 2 OUTPUT
)
(
RECYCLE OUTPUT
)
(
NIGHT OUTPUT
)
(
Turn light ON/OFF setting
)
(
RECYCLE TIMER SETTING
)
(
TEMP setting
)
(
STATUS
)
(
POWER INPUT
)
(
ON/OFF BREAKER
)
Click knob, turn to set, press
again to confirm
Press both knobs for 3
seconds, set clock
FUNCTION KNOBS
