2. Connection diagram of the heater FLOW-14D
Fuel pump
Fuel tank
Fuel line
Exhaust pipe
Coolant pipe
line
Coolant pipe line
Duplicate of
label
Coolant pump
Coolant pump
harness
Control panel
Air intake
mounting kit
Power supply
harness
Fuel pump
harness
Harness
