PAGE 5Help: 888-426-5001 QualityWaterForLess.com
5)
TANK SIZE:
In the first column, identify the
section
containing your softener
Tank Size
by either its grain capacity,
amount of cubic feet, or dimensions. To calculate the amount of cubic feet, take the grain capacity of your tank and
divide it by 32K. For example, a 64K grain capacity tank divided by 32K equals a 2 cubic foot tank. Once you have found
the grain capacity and amount of cubic feet for your tank, record these two values
in the table on page 2.
6)
SALT SETTING:
In the first column, identify the
section
containing your softener
Tank Size
and then within this
section, find the
row
pertaining to your
Hardness
level. Then look under the
Salt Setting
column to find the most effi-
cient program option to select for your
Salt Setting
and record it
in the table on page 2.
7)
Example:
If you ordered a 64K grain capacity system and have 28 gpg compensated hardness, you would look under
the 64K, 2.0 cu ft section and then look under the 20+ gpg row for your particular programming values. Note that the
11x11” and the 15x17” brine tanks are too small for the amount of brine needed to regenerate a 64K grain capacity system
with 20+ gpg hardness. According to the table you would opt for an 18” diameter brine tank with a grid plus 6” legs
TANK SIZE HARDNESS SALT SETTING
lbs of Salt 11x11” Grid 15x17” Grid 18x33” Grid 18x40” Grid 24x41” Grid 24x50” Grid
24K
0.75 cu ft
8x44”
0 - 10 gpg Low 2.25 lbs NO GRID NO GRID NO GRID NO GRID
TOO
LARGE
TOO
LARGE
10 - 20 gpg Standard 6.75 lbs Grid Grid NO GRID NO GRID
20+ gpg High 11.25 lbs Grid + 3” Legs Grid Grid Grid
32K
1.0 cu ft
9x48”
0 - 10 gpg Low 3 lbs NO GRID NO GRID NO GRID NO GRID
TOO
LARGE
TOO
LARGE
10 - 20 gpg Standard 9 lbs Grid + 3” Legs Grid Grid Grid
20+ gpg High 15 lbs Grid + 6” Legs Grid + 3” Legs Grid Grid
40K
1.25 cu ft
10x44”
0 - 10 gpg Low 3.75 lbs NO GRID NO GRID NO GRID NO GRID
TOO
LARGE
TOO
LARGE
10 - 20 gpg Standard 11.25 lbs Grid + 3” Legs Grid Grid Grid
20+ gpg High 18.75 lbs TOO SMALL Grid + 3” Legs Grid + 3” Legs Grid + 3” Legs
48K
1.5 cu ft
10x48”
0 - 10 gpg Low 4.5 lbs Grid NO GRID NO GRID NO GRID
TOO
LARGE
TOO
LARGE
10 - 20 gpg Standard 13.5 lbs Grid + 6” Legs Grid + 3” Legs Grid Grid
20+ gpg High 22.5 lbs TOO SMALL Grid + 6” Legs Grid + 3” Legs Grid + 3” Legs
64K
2.0 cu ft
12x52”
0 - 10 gpg Low 6 lbs Grid NO GRID NO GRID NO GRID
Grid +
5” Legs
Grid +
5” Legs
10 - 20 gpg Standard 18 lbs TOO SMALL Grid + 3” Legs Grid + 3” Legs Grid + 3” Legs
20+ gpg High 30 lbs TOO SMALL TOO SMALL Grid + 6” Legs Grid + 6” Legs
80K
2.5 cu ft
13x54”
0 - 10 gpg Low 7.5 lbs Grid Grid NO GRID Grid
Grid +
5” Legs
Grid +
5” Legs
10 - 20 gpg Standard 22.5 lbs TOO SMALL Grid + 6” Legs Grid + 3” Legs Grid + 3” Legs
20+ gpg High 37.5 lbs TOO SMALL TOO SMALL TOO SMALL Grid + 6” Legs
96K
3.0 cu ft
14x65”
0 - 10 gpg Low 9 lbs Grid + 3” Legs Grid Grid Grid
Grid +
6” Legs
Grid +
6” Legs
10 - 20 gpg Standard 27 lbs TOO SMALL Grid + 6” Legs Grid + 6” Legs Grid + 6” Legs
20+ gpg High 45 lbs TOO SMALL TOO SMALL TOO SMALL TOO SMALL
