Line of Sight Infrared Hydrocarbon Gas Detector AutroPath HC800 , 116-P-HC800/IGB, Rev. A, 2016-03-03
P/N 95-8744, v4.2 , rev. 3/16
Autronica Fire and Security AS
Page 12
TEMPERATURE RANGE—
Operating: –55°C to +75°C (–67°F to +167°F)
Relay version: –55°C to +65°C (–67°F to +149°F)
Storage: –55°C to +85°C (–67°F to +185°F)
Hazardous Locations: Refer to the appropriate
Approval/Certification
Appendix for correct ambient
temperature range.
HUMIDITY—
5 to 99% relative humidity; designed for outdoor
applications.
OPERATING PRESSURE—
91.5 - 105.5 kPA non-compensated.
MEASUREMENT RANGE—
0–5 LFL-meters.
Note: A Negative Zero Drift fault is indicated at –9% of
full scale.
INTERFERENCE RESISTANCE—
Immune to sun and flare radiation, tested to
800 ±50 W/m
2
at ≥ 3° to optical axis and common
contaminants.
SELF-DIAGNOSTIC TEST—
Fail-Safe operation ensured by performing all critical
tests once per second.
MODULE HOUSING MATERIAL—
316 stainless steel (CF8M).
CONDUIT ENTRY OPTIONS—
3/4 inch NPT or M25, with two entries for transmitter and
four entries for receiver.
OPTICS PROTECTION—
Microprocessor controlled heated optics mitigate
against ice and dew formation. Brow provides a degree
of protection against windblown dirt and rain. See
“Mounting Instructions” for brow installation procedure.
INGRESS PROTECTION—
NEMA Type 4X certified,
IP66/67 (Manufacturer verified).
WIRING—
Field wiring screw terminals are UL/CSA rated for up
to 14 AWG shielded wire, and are DIN/VDE rated for
2.5 mm
2
wire. Screw terminal required torque range is
3.5–4.4 lb.-in. (0.4-0.5 N•m).
The receiver can be wired using 3 or 4 wires. The
transmitter requires two wires (power only). The use of
shielded wiring is recommended.
Field wiring for supply connection must be rated to
95°C (203°F).
CERTIFICATION—
For complete approval details, refer to the appropriate
Appendix:
Appendix A- ATEX
Appendix B - IECEx
Appendix C - Additional Approvals
DIMENSIONS—
See Figure 4 for dimensions of the transmitter and
Figure 5 for dimensions of the receiver.
MOUNTING & ALIGNMENT BRACKET ADJUSTMENT
RANGE—
±12 degrees from center, both vertical and horizontal.
WARRANTY—
5 year limited warranty.
10 year warranty on IR source.
SHIPPING WEIGHT—
Transmitter and receiver with mounting hardware:
85 pounds (38 kg)
Replacement Transmitter: 23 lbs (10.4 kg)
Replacement Receiver: 20 lbs (9 kg)
Transmitter Electronics Module: 10.4 lbs (4.7 kg)
Receiver Electronics Module: 7.8 lbs (3.6 kg)
