Autronica AutoPath HC800 - Page 17

Line of Sight Infrared Hydrocarbon Gas Detector AutroPath HC800 , 116-P-HC800/IGB, Rev. A, 2016-03-03
P/N 95-8744, v4.2 , rev. 3/16
Autronica Fire and Security AS
Page 13
16.1
(40.8)
10.8
(27.5)
7. 3
(18.5)
7. 0
(17.8)
7. 5
(19.1)
5.0
(12.7)
5.0
(12.7)
A2659
Figure 4—Mounted Dimensions of AutroPath HC800 Transmitter
in Inches (cm)
5.0
(12.7)
5.0
(12.7)
14.3
(36.3)
10.8
(27.5)
8.1
(20.6)
7. 9
(20.1)
7. 0
(17.9)
A2660
Figure 5—Mounted Dimensions of AutroPath HC800 Receiver
in Inches (cm)
