AUX F Series User Manual

AUX DC Inverter Free Match 50HZ R32
144
NO. Material code Part name Qty
1
11220502004342
Decro panel
1
2
11320135000018
Air louver
（
Horizontal
）
1
3
11220508000139
Filter
2
4
11320096000104
Screw cover
1
5
11320076000084
Medium frame wiring cover
1
6
11320002000305
Medium frame
1
7
11320085000094
Guide vane linkage
1
8
11320017000125
Left-right swing blade
2
9
11320127000007
Step motor bracket
1
10
11320091000014
Crank link
1
11
11320085000081
Guide vane linkage B
1
12
11320062000028
Bearing fixing bracket
1
13
11224003000649
Evaporator assembly
（
07/09
）
1
11224003000764
Evaporator assembly
（
12
）
14
11220513000065
Scroll fan
1
15
11320052000044
Fan motor cover
1
16
11230002000068
IDU fan motor
1
17
11221500000034
Mounting plate assembly
1
18
11320084000013
Pipe clamp
1
19
11320005000381
Horizontal louver
1
20
11320079000016
Step motor shaft sleeve
1
21
11222003002805
Main control assembly
1
