AUX F Series User Manual

AUX DC Inverter Free Match 50HZ R32
146
NO. Material code Part name Qty
1
11321003000028
Mounting plate assembly
1
2
11320084000014
Pipe clamp
1
3
11230005000013
IDU fan motor
1
4
11220513000066
Scroll fan
1
5
11224003000695
Evap asm
1
6
11320052000043
Fan motor cover
1
7
11220551000003
bearing assembly
1
8
11220500000213
Chassis assembly
1
9
11220508000140
Filter
2
10
11320002000303
Medium frame
1
11
11320096000104
Screw cover
1
12
11320003002947
Decorate panel
1
13
11320080000007
Air guiding door fixing pin
1
14
11320005000379
Air louver
（
Horizontal
）
1
15
11222014000608
Display board
1
16
11320076000057
Medium frame wiring cover
1
17
11328001000350
Base EPS B
1
18
11328001000351
Base EPS D
1
19
11320017000125
Left-right swing blade
2
20
11222003002796
Main control assembly
1

AUX F Series Specifications

General

Refrigerant	R410A
Energy Efficiency Class Cooling	A
Power Supply	220-240V, 50Hz
Type	Split
Features	Auto Restart, Sleep Mode
Warranty	1 Year
