Avalon VT-747SP - AC Power Switch

LOW-BASS EQUALIZER BAND
Controls low-bass frequency range:
+/-24dB 15Hz shelf
MID-BASS EQUALIZER BAND
Controls mid-bass frequency range:
+/-8dB 125Hz peak/dip
LOW-MID EQUALIZER BAND
Controls low-mid frequencies0
+/-4dB 500Hz peak/dip
MID-RANGE EQUALIZER BAND
Controls mid frequency range:
+/-4dB 2kHz peak/dip
HIGH-MID EQUALIZER BAND
Controls high-mid frequency range:
+/-10dB 5kHz shelf
HIGH-RANGE EQUALIZER BAND
Controls high frequency range:
+/-20dB 32kHz shelf
AC Power Switch
Turns the power on and off. You must allow
approximately 60 seconds from the time you
turn on the power switch for the Vt-747sp to
complete the entire soft start turn-on proce-
dure. For more details on the soft start pro-
cedure please refer to Chapter 3.5 Turn-on
Procedure.
28
27
26
25
24
23
22
Page 16 Avalon Vt-747sp Operation Manual
Operation and
Controls
AVALON DESIGN
Vt-747sp production at Avalon
