Avalon VT-747SP - Stereo Keyboards; Extreme Compression

5.2.4 Stereo Keyboards
Input: +3
High Gain: Out
TSP: In
Compressor: In
EQ->Comp: Out
Compression Ratio: 6:1
Compression Threshold: -17
Attack: 11 O’clock
Release: Fast
Make-up: +2
Side-Chain: Out
Side-Chain LF Threshold: bypassed
Side-Chain LF Frequency: bypassed
Side-Chain HF Threshold: bypassed
Side-Chain HF Frequency: bypassed
Equalizer: In
EQ Faders from left (1) to right (6):
1. 0
2. +1
3. +1
4. +2
5. +2
6. +1
5.2.5 Extreme Compression
Input: 0 - Unity
Gain: Out
TSP: In
Compressor: In
EQ->Comp: In
Compression Ratio: 20:1
Compression Threshold: -20
Attack: Fast
Release: 12 O’clock
Make-up: +10
Side-Chain: Out
Side-Chain LF Threshold: bypassed
Side-Chain LF Frequency: bypassed
Side-Chain HF Threshold: bypassed
Side-Chain HF Frequency:bypassed
Equalizer: In
EQ Faders from left (1) to right (6):
1. +3
2. +2
3. +1
4. +1
5. +2
6. +2
Page 23
Avalon Vt-747sp Operation Manual
