Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide
13
Rear Panel I/O
Serial Port 1 x RS-232
Ethernet 1 x RJ-45
VGA 1 x DB-15
Audio port 1 x Line out
USB 2 x USB 2.0
KB/MS 1 x PS/2 KB & MS
Camera
1 x USB Camera
(Optional)
Speaker 2W x 2
Mechanical & Environmental
System Fan
Passive Heat Sink
Color
Front & Rear panel Black (Plastics)
Mounting
Wall/Stand/VESA 100 mm X 100 mm
Power Input
100~250 Vdc/ 47~63 Hz
Power Output
+12 Vdc / 7 A (84W)
Operating Temperature
0 to 40°C (32 to 140°F )
Storage Temperature
-10°C to 50°C
Relative Humidity
0%~90% relative humidity, non-condensing
Dimensions
443 x 290 x 59.8 mm 516 x 331 x 55 mm 510 x 352 x 55 mm
Weight
3.90 Kgs TBD 4.79 Kgs
