Avalue Technology PPC-1501 - Rear View

Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide
15
1.4.2 Rear View
Connectors
Label Function Note
COM
Serial port DB-9 male connector
DC in
DC-in power connector
HDD
HDD LED
LAN
10/100/1000Base-Tx Ethernet connector RJ-45
LAN/KBMS
10/100/1000Base-Tx Ethernet connector
or PS/2 keyboard & mouse
RJ-45 or 6-pin Mini DIN
LINE OUT
Line-out audio jack
PWR
Power LED
Reset
Rest button
USB
USB 2.0 connector
VGA
CRT connector DB-15 female connector
