Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide
5
Rear Panel I/O
Serial Port 1 x RS-232
Ethernet 2 x RJ-45
VGA 1 x DB-15
Audio port 1 x Line out
USB 2 x USB 2.0
Speaker 2W x 2
Mechanical & Evironmental
System Fan
Passive Heat Sink
Color
Front & Rear panel Black (Plastics)
Mounting
Wall/Stand/VESA 100 mm X 100 mm
Power Input
100~250 Vdc/ 47~63 Hz
Power Output
+12 Vdc / 5 A (60W)
Operating Temperature
0 to 40°C (32 to 140°F )
Storage Temperature
-10°C to 50°C
Relative Humidity
0%~90% relative humidity, non-condensing
Dimensions
340 x 285 x 53 mm 372 x 324 x 53 mm 510 x 352 x 55 mm
Weight
2.79 Kgs 3.79 Kgs 4.79 Kgs
