49cc Scooter
20
Operation (cont’d)
Instrument panel
z
Speedometer (1):
Indicates the current
driving speed in both
km/h and mph.
z
High beam indication
lamp (2)
: Illuminates
when the high beam is
selected.
z
Turn signal lamp (3):
Indicates that the turn
signal is activated.
z
Fuel indicator (4):
Indicates the fuel level.
When the gauge reads
"F" (Full) the total fuel including reserve is 1.6 gallons (6.06L). The
pointer first enters the red zone when there is about 1 quart of fuel
remaining in the tank.
z
Odometer (5):
Indicates the total distance the vehicle has traveled, in
km.
Seat Lock
z
To open:
Insert the key just below
the seat on the left side of the
vehicle. Press the seat down slightly
while turning the key clockwise to
release the latch. Lift the seat.
z
To close:
Press down the seat until
locked, then remove the key. Never
leave the key in the lock.
53
1
2
4
