Avantree Duet - Page 9

User Manual DUET
9
EN
RCA port
connect the provided RCA adapter (Figure G) to the AUX 3.5mm
audio cable (Figure F). Plug the red & white RCA connectors into
the TV’s “AUDIO OUT” ports, then plug the other end into the trans-
mitter’s AUX 3.5mm input port in the “INPUT FROM TV” section.
Switch the Audio Input Selector on the transmitter to AUX position.
OPTION 3
Input From TV
AUX
AUX 3.5mm
TV
OP
T
AUX
Input From TV
AUX
AUDIO OUT
TV
M
I
C
O
P
T
AUX
