User Manual
8
EN
OASIS PLUS 2
Plug the provided optical audio cable into the TV’s “optical
OUT” or “OPT OUT” port, then plug the other end into the
transmitter’s optical port in the “TX INPUT FROM TV” section.
Optical port (recommended)
OPTION 1
NOTE: Most TVs support audio output through only one
digital output port at a time, so if your TV’s HDMI ARC port
is in use, the optical port may be disabled. You can either
disconnect the HDMI ARC device, or try connecting the
transmitter via RCA / AUX.
TV
OPT OUT
B
OPTICAL
DC IN
AUX AUX
OPTICAL
OPTICAL
Output
To
Speaker
Input From
TV
