Original Operating Manual 1-2013
Example TH11
Legend
Operating computer (Intuvia) On/off button, charge Pedal/ crank
Gear change lever Quick release lever E-motor (Bosch)
Brake lever Saddle Chain guard
Stem (MH7 folding) Seatpost Battery (Bosch)
Headset Carrier Bracket/torque sensor
Front light Rear light Speed sensor
Fork Rear wheel Suspension/ damper
Front wheel Derailleur Frame lock (ABUS)
Valve Gear shifter
Disk brake Stand (Hebie)
Battery lock Chain
