Original Operating Manual 1-2013
Example
fig. 1 fig. 2 fig. 3
IMPORTANT: A loose saddle or shifting saddle positions can lead to dangerous driving situations
and downfalls. Do not drive with a faulty or loose saddle. Always fix the saddle first, before you
are going to ride or step-off the bike.
Installing the battery
If you had removed the battery before assembling the bike, you should now check the charge
status of the battery, before mounting it again. Press the power button on the battery side (see
below). At least 2 to 3 LED’s of the charging indicator should be lit. Otherwise, the battery has
to be recharged for several hours, before you can try out the e-drive.
Example:
On/off switch frame battery carrier battery
For battery mounting, always switch-off the power button first. Keep the case of the frame
battery with the contacts facing down and insert it into the battery holder on the frame tube
(fig. 1). Press the battery into the seat and tilt it to the lock, until the closing mechanism clicks
(fig. 2, 3).
fig. 1 fig. 2 fig. 3
