AVer VB342 Pro Quick Start Guide

English-7
[Note] The BT dongle is an optional item in certain countries. Regarding detailed settings of
Bluetooth, please refer to user’s manual.
Install PTZApp 2
Please go to https://www.aver.com/download-center (Global),
https://www.avereurope.com/download-center (Europe) or https://www.averusa.com/business/support/
(USA) to download the PTZApp 2. After downloading, double-click on the file and follow the on-screen
instructions to complete the installation.
After installing the PTZApp 2, double-click on the PTZApp 2 icon to run the application.
Use PTZApp 2
You can use the PTZApp 2 to set up AI tracking functions, pan, tilt and zoom the camera and some
advanced image and audio settings. Please refer to the user’s manual for details.

AVer VB342 Pro Specifications

General

Pan range	0 - 180 °
Product type	Group video conferencing system
Product color	Black
Tracking modes	Presenter mode
Wall mountable	Yes
Tilt angle range	0 - 105 °
Number of persons	- person(s)
Cable lock slot type	Kensington
Sound pressure level (max)	96 dB
Megapixel	- MP
Sensor type	-
Aspect ratio	4:3, 16:9
Optical zoom	3 x
PTZ protocols	Pelco-P/D, UVC, VISCA
White balance	Auto, Manual
Image sensor size	- \
Diagonal field of view	92 °
Vertical field of view	53 °
Horizontal field of view	84 °
Number of camera presets	10
Remote control interface	IR Wireless
Closest focusing distance	0.8 m
Optical zoom (super-wide mode)	15 x
Processor model	i5-4460
Processor family	Intel® Core™ i5
Applications supported	Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
Windows operating systems supported	Windows 10, Windows 11, Windows 7
Maximum frame rate	60 fps
Video formats supported	H.264, H.265, M-JPEG, YUV, YUY2
Maximum video resolution	3840 x 2160 pixels
Resolution at capture speed	3840x2160@30fps
Supported graphics resolutions	480 x 360, 640 x 360, 640 x 480 (VGA), 800 x 448, 800 x 600 (SVGA), 848 x 480, 960 x 540, 1280 x 720 (HD 720), 1280 x 960, 1600 x 900, 1920 x 1080 (HD 1080), 3840 x 2160
Speaker power	6 W
RMS rated power	12 W
Number of speakers	2
Microphone pick-up range	8 m
AC input voltage	100 - 240 V
DC output current	5 A
DC output voltage	12 V
Power source type	AC
AC input frequency	50 - 60 Hz
Minimum RAM	4000 MB
Minimum processor	Intel® Core i5-4460
Minimum processor speed	3.2 GHz
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB Type-A to USB Type-B, USB Type-A to USB Type-C
Power cable length	3 m
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mounting type	Stand/Wall mounting
LED indicators	Status
Warranty period	3 year(s)

Weight and Dimensions

Depth	116 mm
Width	738 mm
Height	127 mm
Camera weight	3100 g
Package depth	197 mm
Package width	872 mm
Package height	260 mm
Package weight	6300 g
Remote control weight	50 g
Camera dimensions (WxDxH)	738 x 127 x 116 mm
Remote control dimensions (W x H x D)	149.72 x 42.3 x 19.3 mm
