AVer VB342+ Quick Guide


English-1
Quick Guide
SmartFrame and Audio Tracking Functions via
Remote Control?

Manual frame:
Press
button for 0.5sec and will pop up on the top left corner of
the image screen. It takes 3~5 sec to zoom to include all users to fit in the screen.

Auto framing:
Press and hold
button for1~2sec to switch to auto framing mode and
will pop up on the bottom of the image screen. The camera will automatically
detect all faces present and keep stable until people touch the sides of the screen to trigger the
face detection again.

Audio Tracking:
Press and hold
button for 1~2sec. Audio tracking mechanically moves
camera and then zoom the single speaker face. You will see the movement around the room from
the image screen.

Audio Frame:
Press and hold
button for1~2sec. Audio framing detects the speaker and
zoom in his/her face. The camera will be fixed in the central position and uses ePTZ to track the
speaker and zoom in without seeing the movement.

Audio Preset Tracking
: Press and hold
for 1~2sec. Camera will pan to speaker based on
preset points. Please complete the preset points before entering any tracking mode. Ex: Set up
presets in “Manual Frame” or “Tracking off” mode.

OFF:
Press and hold
or 1~2sec to Enable or Disable all tracking functions. Need to enable
before selecting any ‘SmartFrame or Audio tracking mode’
[Note]
Side facial profiles are not detectable.

AVer VB342+ Specifications

General

Pan range	0 - 180 °
Product type	Group video conferencing system
Product color	Black, Grey
Wall mountable	Yes
Tilt angle range	0 - 105 °
Number of persons	- person(s)
Megapixel	- MP
Sensor type	CMOS
Digital zoom	4 x
White balance	Auto, Manual
Image sensor size	- \
Number of camera presets	10
Remote control interface	IR wireless/RS-232
Closest focusing distance	0.8 m
Field of view (FOV) angle	120 °
Aspect ratio	16:4
Maximum frame rate	60 fps
Supported video modes	720p, 1080p, 2160p
Video formats supported	M-JPEG, YUV, YUY2
Supported graphics resolutions	640 x 360, 640 x 480 (VGA), 848 x 480, 960 x 540, 1920 x 1080 (HD 1080), 3840 x 2160
Built-in display	No
Telepresence	-
USB connector type	USB Type-C
Current	5 A
AC input voltage	100 - 240 V
DC input voltage	12 V
AC input frequency	50 / 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB Type-A to USB Type-C
RMS rated power	10 W
Number of microphones	2
Microphone direction type	Unidirectional
Sound pressure level (max)	96 dB
Applications supported	Zoom, Microsoft Teams, Skype for Business, Skype, Google Hangouts, Intel Unite, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting, TrueConf, Adobe Connect, Cisco WebEx, Fuze, GoToMeeting, Microsoft Lync, Vidyo, vMix, WebRTC, Wirecast, XSplit
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Other operating systems supported	ChromeOS
Mobile operating systems supported	Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64
Minimum system requirements	- 2.4 GHz Intel Core 2 Duo - 2 GB RAM
Harmonized System (HS) code	85176990

Weight and Dimensions

Camera weight	2133 g
Package depth	193 mm
Package width	739 mm
Package height	229 mm
Package weight	4160 g
Camera dimensions (WxDxH)	650 x 100 x 109.5 mm
