Avery Berkel FX 110 - FX 120 Display Cable Management; Cable Routing and Securing

7
8
Refer to the drawings on the following pages and:
Place machine upright.
Do not lift the scale by the column display or the weighplate.
9 Replace the weigh plate. Connect to power point.
Caution:
!
!
!
Plug the display cable into the base.
Feed the slack cable round the base.
Secure the cable clips.
