 Connectroundmetalductworktocapandworkbacktowardsthehoodlocation.Use2"metalfoil
ducttapetosealthejoints.

 Option1:Option2:




















INSTALLATIONDRAWINGS


Theminimumhooddistanceabovecooktopmustnotbeless
than28”foranelectriccookingsurfaceandnolessthan30"*
foragascookingsurface.


*
Distancesover30"areattheinstaller’sandusers’discretion,providingthat
ceilingheightpermits
.  









AMINIMUMOF28”ABOVE
ANELECTRICCOOKING
SURFACEAND30"ABOVEA
GASCOOKINGSURFACE
AREREQUIRED
20
TOPCABINET
AIR DUCT
HOOD
STANDARD36’’HIGH
RANGEORLOWER
CABINETRY
Roofcap
Wallcap
Roundairduct
R
ou
n
d

a
ir
duct
