AVG AVM-368PS - Opening Dimensions


PREPARINGTHECUT‐OUT
1. Usingajigsaworreciprocalsawcutanopeninginthebottomofthecabinet,inside theframe .

NOTE: For frameless cupboards, a ¾" (1.9 cm) front and rear edge is required to form a frame in the
bottomofthecabinet.A¾"(1.9cm)thicksupportrod(notincluded)mayberequiredforcertaintypesof
cabinets.
OPENINGDIMENSIONS
3/4"
Model AVM-278PS
¾"
10¾"
26½"
A=Openinginthecupboard
Model AVM-368PS
¾"
’’


 Removethedecorativepanelfromtherangehood.

 Cut a hole in the bottom of the cabinet, using the dimensions shown in the table
above,accordingtothemodel.

 Insert the hood in the cabinet and secure with the (4) mounting screws from the 
innersideoftherangehood.Makecertainthatthehoodissecurebeforereleasing.
Note: Wood blocking might be necessary if there is no frame to secure the
mountingscrews.

 Replacethedecorativepanel.

2. Completetheclosetpreparationaccordingtotheinstructionsforthetypeofhomeevacuation.Determinethe
locationoftheventilationopeningsandcutouttheopeningsinthecupboards,wallsand/orsoffits.
23
¾
"
10¾"
34½"
