STEP 5. RE-MOUNT CALIPER
Re-mount the caliper onto the bike.
TYPE F TYPE N
STEP 6: INSTALL PADS & SPACER
Install the pads and spacer into the caliper and
turn the inboard adjuster knob clockwise to lock
into place.
STEP 7. GREASE CAM PARTS
Grease very lightly the following parts in
preparation for assembly:
-footscrew threads
-tip of stem-end on outer pressure foot
-ramps of drive cam and fixed cam
Grease here
Grease here
Grease here
Grease here
12
